STUDY| Soap bubbles could assist bees with pollination

That could be due to pesticides, parasites, competition with other insect species, climate change, plant loss and a mismatch between the plants available and those that bee species enjoy.

In a world without any or enough bees, it may be possible to pollinate fruit-bearing plants using soap bubbles, according to a study published Wednesday in the journal iScience.

The loss of bees is a "worldwide crisis," said study coauthor Eijiro Miyako, an associate professor in the School of Materials Science at the Japan Advanced Institute of Science and Technology.

"Besides, conventional pollinations like hand pollination are very tough work and annoying for farmers," Miyako said. "They really want a convenient automatic pollination method. They are [the] main reasons why we need to make new artificial pollination."

Machine sprayers reduce human labor and reliance on insects, but have been more expensive and wasteful of pollen grains when they miss the flowers, the study said.

Robotic pollination has become more attractive to researchers since robotic pollinators can detect individual flowers, operate autonomously and be programmed, the study said.

In 2017, Miyako and his colleagues published a study in which they used a tiny drone to pollinate blossoming flowers. Although the drone was only two centimeters in diameter, it destroyed the flowers as it bumped into them because it lacked an autonomous controlling system, Miyako said.

So began the search for another method. While blowing bubbles with his son at a park, Miyako had an epiphany: If the soap bubbles didn't do any damage when they hit his son's face, maybe the bubbles would be soft, light and flexible enough to pollinate flowers without harming them. He confirmed that suspicion with an optical microscopy at his lab.

"It sounds somewhat fantasy, but the soap bubble is effective for pollination," Miyako said.

Bubble pollination

The researchers tested five different commercial surfactants — substances that reduce the surface tension of a liquid, thus increasing the liquid's spreading and wetting properties.

Lauramidopropyl betaine, a surfactant that behaves like soap, was the best option. Its foaming ability produced many stable soap bubbles when researchers triggered the bubble gun once. It also facilitated better pollen germination and growth of the tube that develops from each pollen grain after it's deposited on a flower.

The researchers found that a soap bubble solution with an optimized pH, calcium, other minerals and chemicals was the most effective concentration for germination and for retaining pollen grains on the thin film of the bubbles and transporting them to the targeted flowers.

After three hours of pollination, the pollen activity through the bubbles was higher than that of other methods such as powder pollination or solution pollination (through which powder of pollen grains was applied to the flowers, or a solution of pollen, sugar and agar was sprayed, respectively).

In an orchard, the researchers shot up to 50 pollen-loaded bubbles onto natural pear flowers. Through fluorescence microscopy, they found that the pollen grains landed on the flower pistils and grew pollen tubes. The number of pollen grains on each pistil increased as the soap bubbles grew larger, but the grains decreased and the tubes shortened when more than 10 bubbles were shot, potentially because of toxic accumulation.

After shooting two to 10 bubbles onto the pear flowers, fruits grew after 16 days — at a volume almost the same as that of conventional methods, the study said.

While the fruit-bearing rate of the control group (which didn't undergo pollination) was about 58%, bubble and hand pollination both achieved a rate of around 95%. Soap pollination also called for much fewer pollen grains than other methods did.

"No significant differences were observed between them," Miyako said. "In fact, the shape and size of young pear fruits after soap bubble pollination look the same as hand pollination. But … our method has more potential advantages in terms of future automation and reduction of pollen grains."

The drone experiment

To create a robotic pollinator, researchers combined an automatic bubble maker that produced about 5,000 bubbles per minute with an autonomous, GPS-controlled drone.

Bubbles were shot onto fake lilies (since flowers were no longer in bloom) from a height of about 6 feet. But the bubbles propelled in clusters, and the impact from the wind destroyed the bubbles once they hit the flowers.

When the drone moved more slowly, the researchers found an 87% success rate. That, along with the pollination of the real pear flowers, indicated that a drone with a soap bubble maker could successfully pollinate flowers, the study said.

"[With] this problem of having robots interact with biological systems like flowers or animals, there are a lot of challenges with soft robotics applications," said James Crall, who has researched pesticides and bee health as a postdoctoral fellow in the department of organismic and evolutionary biology at Harvard University. Crall wasn't part of the study.

"[This] was just a really clever idea of using bubbles as a way to interact with these delicate little flowers and using it as a kind of medium you can manipulate for pollination," he added.

Pros and cons of robotic pollination

Despite the study's success, a few factors require further consideration. Additional studies are needed to improve the process so pollen bubbles that miss flowers aren't wasted.

Yu Gu, an associate professor of mechanical and aerospace engineering at West Virginia University who has done separate but similar research, said the study's method was "unique" and "interesting." But his team opted for a ground-based robot instead of a drone since drones had more issues when it came to precision, safety and endurance.

Bubbles also wouldn't be useful year-round since they can't withstand rain or strong winds.

Potential environmental and health impacts of using manufactured soap bubbles to pollinate our food supply aren't yet clear. It's possible that the chemicals used to make the bubbles could accumulate and be difficult to degrade, the study said.

"Certainly we think one of the major threats to pollinator populations in general is the use of agrochemicals," Crall said. "Thinking about the environmental safety of anything we're putting into the environment, especially if we had to do it at scale in massive amounts, is something we should be very, very aware of and concerned about."

Robotic pollination isn't intended to take bees' jobs or to indicate that they're unneeded, both Miyako and Gu said.

"There are multiple motivations for doing robotic pollination research," Gu explained. "One is that we know [bee populations] are shrinking and science has not been able to explain it. So there is a need for a backup plan to have some ability to pollinate flowers, to generate food in case there's a shortage of natural pollinators."

Additionally, many agricultural productions are now in confined spaces such as greenhouses, which could be helped by artificial pollination, he said.

Researchers of multiple disciplines who focus on bee preservation and the science behind the problems are all important, Gu said.

"I don't think that it's a direct competition of resources and engineers and scientists in this regard. It's not like one or the other and we have to choose," Gu added. "I think that the more people are working on this problem, the better. There are so many challenges related to pollination and nature."

However, it would take a long time to implement robotic pollination on a mass scale if needed.

"We get this incredible service from these animals that are remarkably good at flying around [and] locating these little flowers in dense environments, and they do it incredibly efficiently on a massive scale across the globe," Crall said. "I think we're very, very far from being able to imagine replicating all those services that we basically get for free through robotic platforms."

Robotic pollination research is useful and clever, and there might be a narrow role for the technology, Crall said. A potential downside is that public interpretation could lead to a shift from adopting well-known approaches for recovering and preserving bees to the idea of cheaper, more efficient solutions.
